Specification parameter
|
|
system
|
Main Processor
|
GK7102
|
|
image sensor
|
GC1034/GC2053
|
|
Operation System
|
Embedded LINUX OS system
|
|
Video
|
High Definition
|
720P
|
|
Video Compression
|
Smart H.264+
|
|
low illumination
|
0.1LUX/F1.2
|
|
picture Capture
|
Support
|
|
Audio
|
Coding standard
|
G.711
|
|
Two-way Speech
|
Support
|
|
Record management
|
Video file size
|
2.5GB-4.5GB/Day
|
|
Record Mode
|
Manual record, motion detection record, scheduled record, alarm record
|
|
Video storage
|
TF Card/Cloud
|
|
playback, back up
|
Support
|
|
Alarm trigger
|
Video Push,Alarm recording,screen shot capture ,sending Email
|
|
Network
|
Network Interface
|
1*RJ45 , 10/100M10-100 Base-T, self-adaptable Ethernet port
|
|
WIFI
|
802.11b/g/n
|
|
Bitstream
|
Three Stream
|
|
transmission mode
|
P2P,Smart Cloud Sever
|
|
WIFI connection
|
Sweep QR code,Network Cable connection,AP Hotspot Addition
|
|
extend
|
TF Card
|
Maximum support 128GB TF card
|
|
Reset key
|
Support
|
|
power supply
|
Power
|
DC 5V 1.5A
|
|
Power consumption
|
6W
|
|
work environment
|
Suitable place
|
outdoor,Home,shop,School,factory;
|
|
Installation mode
|
Flat put,Wall mounted,hoisting
|
|
Working Temperature
|
-10ºC-+55ºC
|
|
Working humidity
|
10%-90%
|
|
Other
|
Camera lens
|
3.6MM
|
|
Lamp board
|
10 pcs
|
|
Product size
|
58*58*145mm
|
